Terminal Blocks

VEECOTERMINAL STRIPS are moulded either in polythene (flexible) or phenolic bakelite are presently manufactured in 6A, 10A, 15A, 30A, 60A and 100A ratings.

Polythelene moulded strips are recommended for use in temperature for use in temperatures up to 50º C only where as bakelite moulded strips can be used in ambient temperature up to 100º C VTB-6 has enclosed terminals where as VTB-6, VTB-15, VTB-30, VTB-60 and VTB-100 have marked open terminals. All are available with 2, 3, 4, 6, 8, 10 and 12 number of ways.

RANGE

Presently available in 6amp, 10amp, 15amp, 30amp, 60amp and 100amp (Open type & closed type).

CONSTRUCTION

VEECO TERMINAL STRIPS are made of

• Main body are molded from high-grade flame retardant, non-hygroscopic black Phenolic compound. These Terminal strips are also available in PVC.
• Simple construction with minimum no. of parts for simplicity and reliable operation.
• These are available in 7 ways.
• These Terminal strips are of mainly two types Open types & Closed types.

TECHNIAL DATA

Electrical ratings :	30 A at 500 V AC 60 A at 500 V AC 100 A at 500 V AC
Body and End Plate :	Moulded Bakelite
Connecting link :	Brass to casted
Screws :	MS Passivated
Channel :	Steel Passivated
End Clamp and Screw :	Steel Passivated
Test Voltage :	2000 V between adjacent terminals and 2500 V between terminals and channels.
